MOTIVELITHIUM BATTERY FOR ships,BOATS,MARINE,FOR REPLACEMENT OF OLD BATTERIES WITH COMMUNICATION AND REMOTE MANAGE FUNCTIONS.

MOTIVELITHIUM BATTERY FOR ships,BOATS,MARINE,FOR REPLACEMENT OF OLD BATTERIES WITH COMMUNICATION AND REMOTE MANAGE FUNCTIONS. Featured Image
  • MOTIVELITHIUM BATTERY FOR ships,BOATS,MARINE,FOR REPLACEMENT OF OLD BATTERIES WITH COMMUNICATION AND REMOTE MANAGE FUNCTIONS.
  • MOTIVELITHIUM BATTERY FOR ships,BOATS,MARINE,FOR REPLACEMENT OF OLD BATTERIES WITH COMMUNICATION AND REMOTE MANAGE FUNCTIONS.

Short Description:

Designed for applications where long continuous discharge is required, such as powering boat electronics or trolling motors.
Advantages: long cycle life and stable discharge performance.
Application: Long-term offshore operations, such as commercial fishing and long-distance cruising.


Product Detail

Product Tags

Product Detail

1
dghf

Technical Parameter

Model Voltage (V) Capacity (Ah) Energy (kWh) Dimensions (L*W*H,mm) Life Cycle (time) Rated  Discharge (A) Max. Discharge (30s, A) Discharge (℃) Charge (℃) IP Grade
DKFLB-24125 25.6 125 3.2 624*210*627 >4000 125 375 -30~60℃ 0℃-60℃ IP65
DKFLB-24160 160 4.1 624*210*627 160 480
DKFLB-24173 173 4.4 624*195*627 173 519
DKFLB-24200 200 5.1 624*210*627 200 600
DKFLB-24228 228 5.8 624*195*627 228 684
DKFLB-24268 268 6.9 624*284*627 268 804
DKFLB-24302 302 7.7 624*284*627 302 906
DKFLB-24400 400 10.2 624*356*627 400 1200
DKFLB-24536 536 13.7 624*428*627 536 1608
DKFLB-24604 604 15.5 624*500*627 604 1812



Model Voltage (V) Capacity (Ah) Energy (kWh) Dimensions (L*W*H,mm) Life Cycle (time) Rated  Discharge (A) Max. Discharge (30s, A) Discharge (℃) Charge (℃) IP Grade
DKFLB-36405 38.4 400 15.36  798*439*575 >4000 times 400 1215 -30℃~60℃ 0℃-60℃ IP65
DKFLB-36460 460 17.66  965*337*775 460 1380
DKFLB-36536 536 20.58  969*397*775 536 1608
DKFLB-36604 604 23.19  978*689*575 604 1812
DKFLB-36684 684 26.27  973*512*775 684 2052
DKFLB-36804 804 30.87  978*859*575 804 2412



Model Voltage (V) Capacity ( Ah) Energy (kWh) Dimensions (L*W*H,mm) Life Cycle (time) Rated  Discharge (A) Max. Discharge (30s, A) Discharge (℃) Charge (℃) IP Grade
DKFLB-48302 51.2 302 15.46  827*520*627 >4000 times 302 906 -30~60℃ 0℃-60℃ IP65
DKFLB-48346 346 17.72  827*520*627 346 1038
DKFLB-48400A 400 20.48  827*520*627 400 1200
DKFLB-48456A 456 23.35  827*522*627 456 1368
DKFLB-48536A 536 27.44  827*627*627 536 1608
DKFLB-48604A 604 30.92  827*735*627 604 1812
DKFLB-48400B 400 20.48  1220*284*627 400 1200
DKFLB-48456B 456 23.35  1220*352*627 456 1368
DKFLB-48536B 536 27.44  1220*352*784 536 1608
DKFLB-48604B 604 30.92  1220*424*784 604 1812
DKFLB-48456C 456 23.35  1030*352*784 456 1368
DKFLB-48604B 604 30.92  1030*442*784 604 1812
DKFLB-48692 692 35.43  827*735*627 692 2076



Model Voltage (V) Capacity( Ah) Energy (kWh) Dimensions (L*W*H,mm) Life Cycle (time) Rated  Discharge (A) Max. Discharge (30s, A) Discharge (℃) Charge (℃) IP Grade
DKFLB-80320 83.2 320 26.62  1025*564*627 >4000 times 320 960 -30~60℃ 0℃-60℃ IP67
DKFLB-80375 375 31.20  1025*564*627 375 1125
DKFLB-80400A 400 33.28  1025*564*627 400 1200
DKFLB-80456A 456 37.94  1025*708*627 456 1368
DKFLB-80536A 536 44.60  1025*852*627 536 1608
DKFLB-80604A 604 50.25  1025*852*627 604 1812
DKFLB-80692A 692 57.57  1025*996*627 692 2076
DKFLB-48800A 800 66.56  1025*996*784 800 2400
DKFLB-80400B 400 33.28  1025*564*784 400 1200
DKFLB-80456B 456 37.94  1025*708*784 456 1368
DKFLB-80536B 536 44.60  1025*852*784 536 1608
DKFLB-80604B 604 50.25  1025*852*784 604 1812
DKFLB-80692B 692 57.57  1025*996*784 692 2076
DKFLB-80800B 800 66.56  1025*996*784 800 2400



Model Voltage (V) Capacity( Ah) Energy (kWh) Dimensions (L*W*H,mm) Life Cycle (time) Rated  Discharge (A) Max. Discharge (30s, A) Discharge (℃) Charge (℃) IP Grade
DKFLB-309125 307.2 125 38.40  1144*723*414 >4000 times 125 250 -30~60℃ 0℃-60℃ IP67
DKFLB-309150 307.2 150 46.08  1144*723*414 150 300
DKFLB-309228 307.2 228 70.04  1385*694*637 228 456
DKFLB-347173 345.6 173 59.79  1027*760*572 173 346
DKFLB-405173 403.2 173 69.75  1220*670*935.5 173 346
DKFLB-405228 403.2 228 91.93  1300*1220*913 228 456
DKFLB-540228 537.6 228 122.57  1884*715*614 228 456
DKFLB-540456 537.6 456 245.15  1880*1410*622 456 912
DKFLB-579604 576 604 347.90  2480*1356*1030 500 1000
DKFLB-608302 604.8 302 182.65  1900*1410*604 250 600
DKFLB-618456 614.4 456 280.17  2080*864*1520 456 912
DKFLB-618684 614.4 684 420.25  2520*680*943 500 1000



Product Features

hiusd3
hiusd2
hiusd1
